Tag: Linear Regulator

As long as we have a stable voltage reference, a stable voltage source can be produced by amplifying the reference. LM10 provide both the reference and the amplifier, so it need no additional external components to build such system. Here is the schematic diagram of the circuit:

Buffering for the zener is provided by the impedance matching and current amplifying characteristics of the emitter follower and draw less current from it. To a Zener regulator, it’s a useful adjunct. The capacitor on the right circuit is used to reduce ripple. Other variation of capacitor placement for noise reduction, you can just add the capacitor in parallel with […]

Variable output regulator is valuable for your test bench tools. This regulator produce variable voltage source from 1.2 to 17Volts. Series type regulator consist of something equivalent to variable-resistance device, an LM317 for this case. Since series-pass regulator dissipates power and turn it into heat to stabilize the output, this regulator need large heatsink.  The hardest power dissipation occurs at […]

With feedback, we can do very much better and achieve a nearly perfect voltage source. We can see this principle which is shown in the circuit below. Using a voltage divider on the output or the voltage reference, the output voltage is compared with an accurate voltage source such as the 2.5V LM336 to get the desired voltage and the […]
