This circuit is a ultra low noise magnetic phono preamp. This circuit uses an LM381/1A. This circuit also includes RIAA equalization. This circuit has ultra low noise. The DC voltage level at the output of this circuit is about 16.5V, the voltage must be equal to half of the supply voltage. That can be done by adjusting potentiometer R7. Here […]
Read more
Unwanted noise is eliminated by FET. FET also added capacitance caused by long cobias connecting hydrophone to shore station. Voltage gain is unity. Hydrophone preamp can be used with cables up to 3000 feet long. Use 1 Meg resistor between gate and ground to suppress low frequency excursions of signals if hydrophone moves in water. [Circuit’s schematic diagram source: seekic.com]
Read more
Audio mixer is used to mix several audio signal from many channel into one channel, in analog form. The basic requirement of an audio mixer is that the mixed signal is a product of simple addition. When connected to several source, each source should not interfere each other on each input line. If each sources has various DC offset level, […]
Read more
This is The Fet Amplifier circuit. This circuit uses FET transistor. The gate of the FET must be negative with respect to the source, so a bias can be achieved in the following manner. The voltage that is across the source resistor is developed by the drain current flowing through the source resistor. Due to that action, the emitter become […]
