This is a TMP01 temperature out-of-range warning circuit. This circuit is used to generate a temperature out-of-range warning signal. This circuit is usually used in sensitive equipment calibrated to work over a limited temperature range. This circuit can be done by connecting the two open-collector outputs of the TMP01 together into a wired-OR configuration. Here is the schematic diagram of […]
Read more
This is a TMP01 Temperature-to-Frequency Converter circuit. Converting voltage to the frequency domain is another common method of transmitting analog information. This circuit uses monolithic voltage-to-frequency converters (VFCs) that has some advantages like low cost a robust, and has open-collector digital output. The important information is frequency, so it is immune to voltage drops and noise. The temperature data can […]
Read more
This is a TMP01 Temperature Sensor Transmitter circuit. This circuit is used in industrial environments to transmit the signal differentially on a wire pair due to noisy industrial environments. This circuit will reduce errors significantly. Here is the schematic diagram of the circuit: To cancel out the noise very effectively at the receiving end, a receiver with high common-mode input […]
Read more
This is a buffer circuit for TMP01 Temperature Sensor. The output of this sensor is a low impedance dc output voltage with a 5 mV/K temperature coefficient. This sensor can be used in multiple control and measurement applications. The buffered VPTAT voltage output can drive 500 µA into 50 pF (maximum). Here is the schematic diagram of the circuit: To […]
